Marantz AV7706 AV Seperates
Marantz AV7706 AV Seperates
Regular price
$4,399.00
Regular price
$4,599.00
Sale price
$4,399.00
Unit price
/
per
The Marantz AV7706 pre-amplifier features 8K HDMI passthrough, 3D audio formats, audiophile-quality music playback, multi-room HEOS® Built-in technology, and voice control.
- Artisinal Design
- 7 Channels
- 7 HDMI Inputs plus eARC
- 8K Ultra HD
- 3D Audio
- HEOS Built-in
- 1 Year Warranty
Multichannel Surround
- DTS Neo:X / DTS Neural:X No / Yes
- DTS Virtual:X Yes
- IMAX Enhanced Yes
- Dolby TrueHD / Dolby Atmos/Dolby Atmos Height Virtualization Yes / Yes / Yes
- Dolby TrueHD / Dolby Atmos / Dolby Surround No / Yes
- Auro 3D Yes
- Audyssey DSX No
- Multichannel Stereo Yes
- Max Number of Processing (Preamp) Channels 11.2
Sound Enhancements
- Copper Plated Chassis No
- Power Transformer: Toroidal / EI No / Yes
- Current Feedback Topology Yes
- Hyper Dynamic Amplifier Modules (HDAM) Yes
- Pure Direct Yes
- Gold plated RCA terminals Yes
- Clock Jitter Reducer Yes
- Audyssey MultEQ XT32
- Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
- Audyssey LFC Yes
- Compressed Audio Enhancer: MDAX2 Yes
Network
- HEOS Multi-room and Streaming Yes
- Network Audio Sharing Yes
- Lossy formats MP3 / WMA / AAC Yes / Yes / Yes
- Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
- Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24 Yes / Yes / Yes
- DSD Audio Streaming Yes (2.8/5.6MHz)
- FLAC HD 192/24 Yes
- WAV 192/24 Yes
- ALAC 192/24 Yes
- Gapless Playback Yes (FLAC, WAV ,ALAC ,DSD)
- AirPlay Audio Streaming Yes (AirPlay2)
- Internet radio Yes (TuneIn)
- Other Streaming Services * Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
- Compatible with Remote APP for Smart Phones Marantz 2016 AVR RemYeste
- Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
- Ethernet Ports Yes
- Wi-Fi Yes
- Bluetooth Yes
HDMI
- HDMI Inputs: Back / Front 7 / 1
- HDMI Outputs: Main / Zone 2 / 1
- Video Conversion Analog -> HDMI Yes
- Analog to HDMI Scaling 480i/576i up to 8K 60/50
- HDMI to HDMI Scaling up to 8K 60/50
- GUI Overlay on HDMI Yes
- Enhanced ARC Yes
- 3D Signal Pass-Through Yes
- 4K Signal Pass-Through / Scaling / GUI Overlay Yes / Yes / Yes
- HDMI Pass-Through in Standby Mode Yes
- Picture Adjust / Noise Reduction Yes / Yes
- CEC Yes
- DSD Audio Capability Yes
- Audio Return Channel Yes
- Auto LipSync Yes
Multi-Room CI
- HEOS Multi-Room Integrated Yes
- HEOS Link Compatibility: IR/ IP Yes / Yes
- Multi-Room Zones 3
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
- Zone Audio Output: Speaker / Preout No / Yes
- Zone HDMI Output from HDMI Source Yes
- IP Control / RS232 Control / Web Control / App Control Yes / Yes /Yes / Yes
- IR Flasher In Yes
- Marantz Remote Bus Yes
- DC Trigger Output 2
- HDMI Diagnostics Yes
Others
- Auto Speaker Setup by Microphone Audyssey MultEQ XT32
- FL Display 2 lines + port hole
- Graphic User Interface - GUI Advanced
- ISF Certification Yes
- GUI Languages 3
- Smart Select Yes
- Firmware Update by Network USB Yes / Yes
- Variable Cross Over Yes
- Optimized Bass Redirection Yes
- Bass Sync Yes
- ECO Mode No
- Auto Power off Yes
- Sleep Timer Yes
Inputs Outputs
- Composite In / Out 3+1 / 2
- Component In / Out 3 / 1
- HDMI In / Out 7+1 / 3
- Multi-Room Video Out: Video / HDMI Yes / Yes
- Analog In / Out 5+1 / No
- Phono (MM) In Yes
- Digital In: Optical / Coaxial 2 / 2
- Multi-Room Out: Analog / Digital 2 / No
- Multichannel Pre Out Yes (11.2 RCA & 11.2 XLR)
- Subwoofer Out 2 (independant)
- 7.1 Multichannel Input Yes
- Speaker A B assignable pre out
- Bi-Amp Drive assignable pre out
- Multi-Room Speaker Terminal pre out
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB Yes / Yes / No / Yes / Yes
- USB Audio / Made for iPod® / Made for iPhone® Yes / No / No
- AM/FM Tuner Yes
General
- Metal Front Panel Yes
- System Remote Control RC044SR
- Pre-Programmed / Learnable / LCD Display Yes / No / No
- Power Consumption in W 60
- Power Consumption No-Sound (ECO on/off) in W No
- Standby Consumption in W 0.2
- CEC Standby Consumption in W 0.5
- Network Standby Consumption in W 3.5
- Network Control On Consumption in W TBD
-
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in inches
Antenna:Vertical :(W x D x H) in inches
W/o Antenna:(W x D x H) in inches 17.3 x 16.2 x 7.3
( 17.3 x 16.2 x 9.7 )
【 17.3 x 15.8 x 7.3 】 - Weight in lbs. 22.9 (TBD)
